Gas spring with dynamic damping

These gas springs with full-stroke damping have been specially developed for the protection of delicate products, such as LCD screens, expensive high-tech equipment, technical machines, and medical equipment. The gas springs are available in the sizes 6/15, 6/19, 6/22, 8/19, 8/22, and 10/22.

Compared to standard gas springs that only have controlled oil damping at the end of the stroke, these gas springs provide full-stroke damping. The desired damping properties are applied in the form of a tapered groove completely to customer specifications. This tapered groove is filled with oil as soon as the piston rod enters or exits.

Benefits of gas springs with dynamic damping

This type of damping has a number of advantages. For example, not only can controlled damping be achieved over the entire stroke, but the way in which the gas spring is mounted (with piston rod pointing upwards or downwards) does not affect the damping properties.

In order to use the tapered groove for your specific project, we require detailed information about the gas spring's final application and function.

Would you like to know more about the possibilities of gas springs with dynamic damping? Please contact our gas spring specialists.
