MC-damper standard

Power (N)              Stroke               Diameter

7-40.000 N               10-1000 mm          3/10-30/70

This specification with damping over the complete stroke contains only oil. Due to the construction, there will be a small free travel when the piston rod is pulled out. The push-in and push-out speed – i. e. the effective slowing down (motion control) of the movement of a mass – can be influenced considerably by the use of different nozzles as well as by different oil viscosities.
