Innovative threaded self-locking lifting pins for building cleaning, beamers, theater and construction sector.

BIBUS offers you a comprehensive range of self-locking lifting pins. New in this collection is the innovative, easy-to-use, self-locking lifting pins (AP28 and AP29). These new lifting pins can be clicked into threaded receptacles.

Benefits

• fast assembly by clicking in and out;
• large lifting capacity;
• minimal effort;
• maximum reliability in use;
• suitable for various materials;
• replaces a permanent lifting pin.

The new model can be used in M10, M12 and M16 diameters. H11 holes are no longer required for use. This makes it possible to work faster with these lifting pins. The threaded self-locking lifting pins are clicked in and out, they no longer need to be turned off. The threaded self-locking lifting pins are available in steel and stainless steel. Depending on the design and material, the maximum force ranges from 3.9 to 8.4 kN for in-line lifting and 1.5 to 4.5 kN for lifting at an angle of 45 °. Each model meets safety factor 5, is corrosion-resistant and has a maximum temperature range of 250 ° C.

Also view our total assortment of lifting pins here.

Different markets

The threaded self-locking lifting pins are also useful for the theater and construction sectors;

• molds, stages, fixtures, light spots;
• ceiling systems.

Video

Watch the video for the many benefits of these innovative lifting pins.
